Receive the real -time positioning of the sensor, the position, direction, and distance of the rapid positioning of multidimensional navigation;
Display the measurement value in real time, and automatically lock the real thickness;
The upstairs host screen and downstairs synchronous monitor shared the detection data in real time to facilitate communication and improve efficiency;
Comes with reinforced steel position interpretation and reinforced density correction function to reasonably arrange the detection area to improve the data
accuracy;
Support instrument calibration, effectively solve environmental factors affect the thickness deviation of the thickness;
Comes with Bluetooth module to support real -time data upload;
PC professional data analysis software, data processing and report generation easy completion.

GB 50204-2015 "Code for the Construction Quality Acceptance of Concrete Structure Project"
JJF 1224-2009 "Standard Specifications for the Protective Flash of Reinforced Bar Acers, Building thickness measurement instrument"

Direction indication range (m): X direction: 0.2 ~ 1.5; Y direction: 0.2 ~ 1.2
Measurement accuracy (mm): 20-350 ± 1; 351-600 ± 2; 601-900 ± 3
Data storage capacity: 1000 components or 2200000 measuring points
Host power supply: built -in large -capacity lithium battery can work for 24 hours
Probe power supply: built -in large -capacity lithium battery can work for 64 hours
Synchronous display: built -in large -capacity lithium battery can work for 48 hours
